OTA سیستم های تست آنتن و اتاق های

خلاقانه. دقیق اثبات آینده

مدل های موجود

کاربرد	منطقه آرام	ابعاد بیرونی (W x D x H بر حسب متر)	اثر محافظ	رنج فرکانس	نام محصول
R&D, Conformance & pre-conformance (RF, LBS, Netop, PCT, PQA)	Ø 30 cm	0.9 x 1.5 x 2.0	>90 dB (typ.)	18 GHz - 90 GHz	R&S®ATS1800C
Automotive radar R&D, calibration, validation, pre-compliance testing	Ø 30 cm	0.9 x 1.6 x 2	>90 dB (typ.)	6 GHz - 110 GHz	R&S®ATS1500C
R&D, pre-conformance (RF, LBS, Netop, PCT, PQA	Ø 20 cm	0.8 x 1.0 x 2.1	>40 dB (typ.)	20 GHz - 50 GHz	R&S®ATS800R
Benchtop R&D, academia, research institutes	Ø 20 cm	1.2 x 0.6 x 0.8	N/A	20 GHz - 50 GHz	R&S®ATS800B
R&D, antenna measurements	Ø 4 cm @ 40 GHz	1 x 1.5 x 2.1	>50 dB	18 GHz - 87 GHz	R&S®ATS1000
Base station testing for R&D and production	Ø 1.1 m @ 1.5 m distance	depends on chamber	depends on chamber	1.7 GHz - 5 GHz	R&S®PWC200
R&D, production sample testing, diagnostics		0.77 x 0.7 x 0.76	100 dB	0.4 GHz - 18 GHz	R&S®DST200
R&D, production, 5G FR2 device/components	Ø 2 cm @ 40GHz	0.45 x 0.7 x 0.6	>60 dB	20 GHz - 77 GHz	R&S®CMQ200
R&D, production, 5G FR1 & FR2 device/components LBS, NPT	Ø 2 cm @ 40GHz	0.45 x 0.7 x 0.6	>80 dB	0.7 GHz - 77 GHz	R&S®CMQ500
